Outdoor power distribution solutions up to 1000 A
* Design verification up to 1000A in accordance with IEC 61439-1/-2/
* IP65 protection class
* High strength with welded 1.5 mm structure
* 6.25 mm precise movement capability in internal components
* 316L Stainless steel hinges
Protection class according to IEC 60 529: IP65
IK CODE: IK10
SURFACE TREATMENT: Nanoceramic coating
COATING: Ral 7035 wrinkle UV resistive polyester powder coating
LOCK: Polyamide handle with key, 3 points latch
HINGES: Hidden hinges, stainless steel 130° opening angle
INSETS: Door earthing cable (1 piece for each door)
GTIP CODE: 8538.10.00.00.00
CERTIFICATES:
IEC 62208-TSE
IEC 60529 IP65 Test
IK10 Test
IEC 60068-3-3 Seismic Test
GR63 Core Seismic Test
ASTM 4169-16 Transportation Test
Wind Resistance Test
IEC TR 61439 – 1000A
EAC Certificate
RED Certificate
DECLARATIONS:
CE Declaration of Conformity
