It’s a shelter!
Ready for all challenging weather conditions with IP65 protection class and 2,5mm welded body structure.
Some advantages of H series;
* Flexible, adjustable swing and fixed frame positions with 25mm steps.
* Swing Frame load tested up to 160 kg.
* Adjustable opening angles of swing frame from 130 to 180 degrees.
* Improved swing frame design allows mounting of 19’’ devices with up to 435 mm depth
Protection class according to IEC 60 529: IP65
IK CODE: IK10
SURFACE TREATMENT: Nanoceramic coating
COATING: Ral 7035 wrinkle UV resistive polyester powder coating
LOCK: Polyamide handle with key, 3 points latch
HINGES: Hidden hinges, stainless steel
130° opening angle
INSETS: Door earthing cable (1 piece for each door)
GTIP CODE: 8538.10.00.00.00
CERTIFICATES:
IEC 62208-TSE
IEC 60529 IP65 Test
IK10 Test
IEC 60068-3-3 Seismic Test
GR63 Core Seismic Test
ASTM 4169-16 Transportation Test
Wind Resistance Test
EAC Certificate
RED Certificate
DECLARATIONS:
CE Declaration of Conformity
